GI Pipe In Strip
Veraizen Earthing provides high-quality GI Pipe In Strip in major cities of India and also exports to more than 80 countries worldwide. All GI Pipe In Strip are of International Quality Standards(IQS).
GI Pipe In Strip Manufacturer in India
Veraizen Earthing are leading GI Pipe In Strip manufacturers in Mumbai India. We provide GI Pipe In Strip available in different grades. Our high-quality range of GI Pipe In Strip are exclusively designed for steel factories, petrochemical industry, fire protection systems, chemical industries, shipping/shipment industries, etc. We offer GI Pipe In Strip and more. Our GI Earthing Strips can be installed to help minimise soil resistance and make it easier to sweep defective currents away using the dissipation technique. Our GI strips provide a complete and comprehensive solution for earthing needs in the long run, due to its high quality of material and durable construction that meets international quality standards. All GI Pipe In Strip are designed and developed in accordance with IQS (International Quality Standards). Our Gi Pipe In Strip are made with precision using the best quality raw materials. We also offer customized GI Pipe In Strip as per the customers requirement.
GI Pipe In Strip Specification
| Usage/Application | Industrial |
| Material | Galvanized Iron |
| Finish | Polished |
| Rod Diameter | 16 - 50 mm (Width) |
| Thickness | 3 - 5 mm |
| Length | 5 - 6 meter |
GI Pipe In Strip Size Chart
| Width mm. | Thickness mm. | Weight Kg. Gms. | Width mm. | Thickness mm. | Weight Kg. Gms. |
|---|---|---|---|---|---|
| 25 | 3 | 0.6 | 65 | 6 | 3.06 |
| 25 | 6 | 1.2 | 65 | 10 | 5.1 |
| 32 | 6 | 1.5 | 65 | 12 | 6.12 |
| 32 | 3 | 0.75 | 75 | 6 | 3.53 |
| 40 | 6 | 1.88 | 75 | 10 | 5.89 |
| 50 | 6 | 2.5 | 75 | 12 | 7.07 |
| 50 | 10 | 3.93 | 100 | 6 | 4.71 |
| 50 | 12 | 4.71 | 100 | 10 | 7.85 |
| Also Available in : ZINC COATED STRIPE, HOT DIP GALVANIZED EARTHING STRIPE. | |||||
About GI Pipe In Strip
We are a leading manufacturer and supplier of GI Pipe In Strip in India. The primary earthing pipe or bar is connected to the galvanised iron pipe earthing strip, or GI Strip. It is mostly used to guarantee that the specified minimum earth resistance is met when installing the equipment. Our GI Strips are made with high-quality raw materials that satisfy international standards at Subham Enterprise. The strips are then hot-dip galvanised in accordance with industry standards IS:4759. Our GI Earthing Strips can be installed to help minimise soil resistance and make it easier to sweep defective currents away using the dissipation technique. Our GI strips provide a complete and comprehensive solution for earthing needs in the long run, thanks to the high quality of material and durable construction that meets international quality standards. We also deal in GI Earthing Electrode in India.
Benefits of our GI Earthing Strips:
- The installation process is easy and hassle free
- Raw materials used to manufacture the strips match up to the international standards, resulting in high efficiency.
- The strips are coated with Hot Dip Galvanization
- The construction is robust and seamless with fine finishes.
- The strips are resistant to adverse climatic conditions
- Corrosion free solution which remains durable and long lasting.
- Customizations are available as per the requirements of the client.
Related Types of GI Earthing Electrode
| Related Type of GI Earthing Electrode | |
| GI Pipe In Pipe Technology | Copper Strip in Pipe |
| Gi Earthing Electrode | |
